235

Series 235 Thermoplastic 2 Way Normally Open Direct-Acting Solenoid Valve Ultravalve supplies the Series 235 2 way normally open direct-acting poppet type solenoid valve for automated on/off flow isolation in compatible industrial and food related fluid systems. Constructed with a certified thermoplastic polymer body, the Series 235 is designed for compatible food applications and industrial processes requiring dependable normally open operation and direct-acting control from 0 bar differential pressure. In its de-energised state, the valve allows flow and closes when energised, subject to correct specification, media compatibility and installation. Dependable Normally Open Control for Industrial and Food Compatible Fluid Applications Ultravalve’s Midlands based warehouse offers a wide range of Series 235 valves from stock, subject to configuration and current availability. Designed to support maintenance projects, compatible fluid handling systems and industrial process upgrades, these valves help provide fast replacement options for urgent pipework and general process requirements. Normally Open Direct-Acting Performance: The 2 way normally open direct-acting poppet type design enables electrically actuated on/off flow isolation from a minimum differential pressure of 0 bar. Certified Thermoplastic Construction: Manufactured with a thermoplastic polymer body certified to ACS, KTW, W270, WRAS, NSF and FDA standards, alongside a brass chemically nickel plated armature tube, AISI 430FR plunger and core and AISI 302 springs. Defined Pressure & Flow: Supports a maximum allowable pressure of PS 20 bar, with pressure suitability related to the type of connection and pipe used. Maximum differential operating pressure reaches up to 14 bar on selected 1.5 mm configurations. Available with 1.5 mm, 2 mm and 2.5 mm orifice sizes, with Kv values from 0.06 to 0.14 m³/h. Versatile Connection Options: Available with spiggot, G1/8 male thread with nut for flexible pipes, hosetail, compression for flexible and semiflexible pipes, and push in fittings for semiflexible pipes with Øext 6 and Øext 4 options. Seal & Fluid Compatibility: Seal materials are listed as NBR, FPM and EPDM, with suitability dependent on valve code, media, temperature, valve body, connection type and application compatibility. Maximum fluid viscosity is listed as 25 cSt. Steam Application Constraint: The maximum allowable pressure for steam applications is strictly limited to PS 2.5 bar gauge. Electrical Duty & Protection: Uses compact Series 3 coils with continuous service ED100%. Electrical connection is DIN 46244 with PG9 connector, with protection rated IP65 when the connector is fitted and IP00 without connector. Options & Temperature Guidance: Available with stainless steel armature tube, Type N connection without nut, Class H insulation, cable attached versions, special coil voltages, special coil powers and certified coils. Ambient temperature is listed as -10°C to +80°C according to the coil, with temperature range dependent on seal material, valve body and connection type. With over 30 years’ experience and an ISO 9001:2015 certified quality management system, Ultravalve provides dependable valve solutions for UK industry. The Series 235 thermoplastic normally open direct-acting solenoid valve is available to order, with delivery options confirmed at quotation, contact our team for technical advice or to request a quote.
