BA195
Honeywell (Resideo) BA195 Flanged RPZ Valve for Commercial Water Systems (Backflow Preventer)
Working Temperature:
Max 65°C
Body Material:
Ductile Iron (Powder Coated)
Working Pressure:
PN10
Connection Type:
Flange
Key Features & Benefits:
Heavy Duty Construction: features a powder coated ductile iron housing with a stainless steel discharge valve for maximum longevity in demanding environments.
Complete Network Protection: a triple security system uses two check valves and a discharge valve to guarantee protection against backflow and syphonage.
Certified Compliance: approved to EN 12729 and protects drinking water up to liquid category 4 (EN 1717).
Streamlined Maintenance: the fully replaceable internal cartridge allows for rapid, in-line servicing without dismantling the primary pipework.
High Flow Efficiency: optimised internal geometry ensures high flow rates with minimal pressure loss and prevents water stagnation.
Securing large scale drinking water networks requires robust high capacity flow control. The Resideo Braukmann BA195 (traditionally specified as the Honeywell BA195) is a heavy duty flanged RPZ valve (backflow preventer) engineered to protect commercial and industrial water systems from contamination caused by back pressure, backflow and back syphonage. Manufactured with a highly durable, and powder coated ductile iron housing, the BA195 delivers exceptional reliability while remaining fully compliant with EN 1717 (protecting up to liquid category 4). For process engineers and maintenance teams, the BA195 drastically minimises operational downtime. It features a combined check and discharge valve cartridge alongside an integrated inlet strainer. This smart internal design allows for full inspection, servicing and component replacement without ever having to remove the flanged valve body from the pipework.
