GLOVALVE 316 NBR
Glovalve AISI 316 NBR Ball Check Valve
Working Temperature:
0°C to 90°C
Nominal Pressure:
PN16
,
Body Material:
Stainless Steel (1.4401)
,
Connection Type:
Threaded
,
Flange
,
Key Performance Capabilities:
Heavy Media Management: The Glovalve NBR ball check valve integrates an NBR-covered steel ball, preventing internal blockages when handling dense liquids or fluids with suspended elements to eliminate unplanned pipeline maintenance.
Material Degradation Resistance: The Glovalve check valve uses pressed 1.4401 EN 10088 (AISI 316) stainless steel across the primary body and cover components, preventing corrosive media attacks to extend operational lifespans and reduce replacement expenditures.
Structural Integrity & Testing: The Glovalve NBR check valve features TIG welded joints manufactured without additional material, with every individual unit undergoing a 3 bar compressed air hydraulic test, guaranteeing structural reliability under continuous pressure loads to prevent pipeline failures.
The Glovalve AISI 316 NBR ball check valve guarantees unidirectional flow isolation for dense and loaded industrial liquids. The Glovalve NBR accommodates nominal sizes from DN 32 to DN 50, regulates operating pressures up to 16 bar, and withstands continuous media temperatures ranging from 0°C to +90°C. Safety & Compliance: Connection Standards: The Glovalve NBR ball check valve incorporates UNI ISO 228/1 female threaded ends, alongside an optional UNI EN 1092-1 PN 16 flanged DN 50 version, ensuring secure integration into established UK pipework architectures to prevent connection failure. Note: The maximum operational media temperature and pressure ranges depend strictly on the specific valve configuration and selected connection standard for the Glovalve NBR check valve.
