CROMAX AP 316
Cromax AP High Pressure Single Disc Check Valve
Working Temperature:
-20°C to 240°C
Nominal Pressure:
PN63
,
Body Material:
Stainless Steel (1.4408)
,
Connection Type:
Threaded
,
Key Performance Capabilities:
High Pressure Structural Integrity: The Cromax AP check valve uses shot-blasted SS 1.4408 (AISI 316) stainless steel across the primary body and internal spring components, preventing structural deformation under continuous 63 bar pressure loads to eliminate catastrophic pipeline failures.
Extreme Thermal Resilience: The Cromax AP check valve integrates a robust metal to metal sealing system, bypassing the thermal degradation limits of standard elastomer seals to guarantee secure flow isolation across severe temperature shifts up to +240°C, thereby preventing unplanned maintenance downtime.
The Cromax AP high pressure single disc check valve provides rigorous unidirectional flow isolation for demanding industrial fluid pipelines. The Cromax AP accommodates nominal sizes from DN 8 to DN 100, regulates extreme operating pressures up to 63 bar, and withstands continuous media temperatures ranging from -20°C to +240°C. Safety & Compliance: Connection Standardisation: The Cromax AP high pressure check valve features EN 10226-1 (ISO 7-1) female gas threaded ends, ensuring standardised, secure integration into established UK high pressure pipework architectures to prevent hazardous thread leakage. Note: The maximum operational media temperature and pressure ranges depend strictly on the specific valve configuration and selected connection standard for the Cromax AP check valve.
