UVQF102MF
1PC ANSI Flanged Ball Valve
Actuation:
Handle
Body Material:
Stainless Steel
Bore Type:
Full Bore
Connection Type:
Flange
,
Working Temperature:
-20°C to 180°C
The UVQF102MF is a 1PC ANSI flanged ball valve providing a robust and straightforward solution for industrial fluid isolation.
Manufactured using investment casting, the valve features a full port design to promote unrestricted flow and minimise pressure losses through the valve. A blow-out-proof stem provides additional operational safety, while PTFE/RPTFE seating and packing materials support reliable sealing performance.
The valve is designed with ANSI B16.5 Class 150 flanged connections, making it suitable for integration into a wide range of process and industrial pipework systems. Its one-piece body construction provides a compact and durable valve solution for applications requiring reliable manual shut-off and dependable long-term operation.
