GEMÜ B56

The GEMÜ B56 3-piece 2/2-way motorised metal ball valve provides automated flow control for industrial processes and water treatment applications. The GEMÜ B56 accommodates nominal sizes from 1/2" (DN 15) to 4" (DN 100), regulates operating pressures up to 40 bar, and withstands media temperatures ranging from -20°C to 180°C. Key Performance Capabilities: Automated Flow Regulation: The GEMÜ B56 integrates a motorised actuator (available in 12 V DC, 24 V DC, 24-240 V AC/DC or 230 V AC configurations) with a built-in optical position indicator, eliminating manual pipeline intervention and preventing process downtime. Leak Proof Spindle Security: The GEMÜ B56 features a triple spindle seal system comprising a 45° conical seal, a stabilising FKM O-ring and pretensioned PTFE V-rings, preventing media leakage and lowering long term component replacement costs. Optimised System Footprint: The GEMÜ B56 uses a compact flanged housing design, facilitating installation in restricted pipework spaces without compromising structural integrity or full-flow bore rates. Safety & Compliance: Explosive Environment Security: The GEMÜ B56 features an integrated antistatic unit and ATEX 2014/34/EU conformity, preventing ignition risks to guarantee facility safety within volatile industrial zones. Sanitary Process Compliance: The GEMÜ B56 achieves FDA and TA Luft conformities alongside Regulation (EC) No. 1935/2004, ensuring plant engineers can standardise one automated metal ball valve across strict food grade, emission controlled and sanitary processing lines. Note: The maximum operational media temperature and pressure ranges depend strictly on the specific ball valve configuration and selected connection standard for the GEMÜ B56.
